| b (mm) |
220.300 |
| c1 (mm) |
145.000 |
| c7 (mm) |
78.200 |
| c8 (mm) |
145.000 |
| c9 (mm) |
100.000 |
| d1 (mm) |
127.000 |
| Dust discharge diameter connection |
54.000 |
| Dust valve type |
STRAIGHT, SM. Ø52mm (Ø54mm) |
| Elbow included |
No |
| Elbow type |
NO |
| Filtration efficiency |
>99,97% |
| Gross weight (kg) |
6.164 |
| h1 (mm) |
435.700 |
| h2 (mm) |
34.000 |
| h5 (mm) |
78.200 |
| h6 (mm) |
205.000 |
| h8 - 5 |
89.500 |
| h8 - 6 |
86.000 |
| h32 (mm) |
346.300 |
| Initial pressure drop (mbar) |
35.600 |
| k1 (mm) |
190.000 |
| k2 (mm) |
316.300 |
| Operating temperature max. (°C) |
100.000 |
| Operating temperature min. (°C) |
-40.000 |
| Pre separation efficiency |
Upto 95% |
| Product width (mm) |
220.300 |
| Secondary element included |
Yes |
| Service life (h) |
13.800 |
| Service life according to (h) |
ISO 5011 mit ISO-grob |
| Splash water protected |
No |
| t (mm) |
218.700 |
| Tightening torque (clean side) (NM) |
5.000 |
| Tightening torque (threaded insert) (NM) |
15.000 |
| Nominal flow rate air (m³/min) |
14.000 |
