Hydraulic Filter Systems
LPS 09 270
1498430S01
About this item
Nominal Flow Rate: 60-110 L/min
Filter fineness with 99% separation efficiency: 10
Operating Pressure: 25 Bar
Product highlights and benefits
-
Quick and clean filter replacement
-
Rugged, space-optimized and reliable design
-
Lower risk of dirt ingress compared with using normal housing filters
| Data | Value |
|---|---|
| Nominal flow rate oil (min) (l/min) | 60 |
| Nominal flow rate oil (max) (l/min) | 110 |
| Operating pressure | 25 Bar |
| Filter fineness with 50% separation efficiency (µm) | 4 |
| Filter media material OE | GLASS FIBER+POLYESTER |
| Filter fineness with 99,5% separation efficiency (µm) | 12 |
| Product length | 273.8 mm |
| Connect thread | G1” |
d1
1-12 UNF mm
d2
62 mm
